744T

4-Channel CF Recorder with Ambient Lockit Timecode

744T
744T panel L
744T panel R
744T back
User Guide | Fact Sheet | Front Panel Shortcuts | FirmwareWave Agent | Accessories

The 744T is a compact, high-resolution four-track digital audio recorder with timecode. The 744T records to its internal hard drive, removable Compact Flash cards, external FireWire drives, or any combination of the three.

With sample rates between 32 kHz and 192 kHz plus full read/write time code, the 744T is the perfect tool for any critical recording environment — from over-the-shoulder to cart-based production.
Purchased Parts Package
744T Recorder
CS-MAN
Bag CS_man-Th
XL-WPH3
Power supply
XL-B2
Battery XL-B2-Th
XL-14
Cable
XL-RJ
Cable
XL-1394
FireWire Cable XL-1394-Th
… more about Sound devices recorders
Technical Details
Two-channels of Sound Devices next generation microphone preamps with phantom, limiters, and high-pass filters
Channel 3 and 4 line-level inputs on TA3 connectors
Two-channel, balanced mic/line level outputs on TA3 connectors
Input-to-track assignment with 256 possible routing combinations
Record to its internal 80 GB hard drive, removable CompactFlash, external FireWire drive, or any combination of the three
AES3 (XLR) or AES3id (unbalanced AES on BNC) digital inputs and AES3id outputs
Programmable, sunlight-viewable LED level metering
WAV (Broadcast Wave compliant), mono or poly files, uncompressed PCM audio
24-bit or 16-bit (with or without dither) and sampling at 32 kHzÐ192 kHz
Ultra-stable Ambient time code circuitry, tuneable to <0.2 PPM accuracy with all relevant TC rates
MP3 and FLAC record and playback capability
FireWire (IEEE-1394) port for high-speed data transfer to computers
6-pin modular C. Link serial input and output for unit linking and future control and expansion
Removable Li-on rechargeable battery compatible with Sony M- and L-mount Li-on batteries
10Ð18 VDC external input powers and charges on-board battery
Aluminum & stainless-steel chassis for exceptional durability and light weight
Class-defining compact size
Designed for the same operational environmental extremes as Sound Devices field mixers
Dimensions (WDH): 209 x 125 x 45 mm
Weight (unit only): 1,2 kg
