DPA Microphones

4071 CORE ENG/EFP Microphone Set

4071 CORE ENG/EFP Microphone Set

Get the interview. Keep the distance.

Regular price 655,00 EUR

excl. VAT

Regular price Sale price 655,00 EUR
Sale
  • Extremely rugged and reliable
  • Enhances speech intelligibility
  • Resistant to moisture, extreme temperatures and humidity
  • Built-in shock mount for stability even in difficult situations
  • Available with 10+ mounting options for flexibility
  • Modular adapter system fits most professional wireless systems

Ready to ship in 14 days

Item number: A05134

The 4097 CORE Interview Kit makes it easy to deliver great sound in challenging situations. It contains a 4097 CORE Shotgun Microphone, which shines in outdoor locations, handling inclement weather and limiting intrusive background noises. It’s a professional solution for professional broadcasters, who need amazing sound in a lightweight, small-footprint form factor.

Free-standing solution

Mount the microphone on a tripod via the cold shoe mount and use it as a stationary interview mic on a table.

Transmitter-direct solution

Mount the microphone directly on the transmitter and place it on a podium or table. This is a quick and easy mic solution with a very small presence.

Voice-over recording

For on-the-go voice-over work, there are a number of DPA accessories that quickly turn the mic into the perfect tool for your situation.

A flexible and light solution

For a team doing on-location interviews, especially outdoors, it is important to have professional tools that make the entire process easy and flexible enough for any situation.

When you’re doing distance interviewing inside or out, the 4097 CORE Interview Kit gets you up and running quickly and easily. No extra equipment. No complicated setup. No workflow changes. A lighter, more flexible solution lightens your bag and eases your work.

Interview at (more than) arm’s length using the 4097 CORE Micro Shotgun Mic attached to an extremely lightweight telescope boom. It doesn’t get any easier or lighter (330 g (11.6 oz) without transmitter). The solution collapses down to only about 40 cm (16 in) and extends all the way to 140 cm (55 in).

Clip your existing transmitter into the holder at the bottom of the pole, connect it via a wireless DPA adapter (not included) and you are ready to go. For larger transmitters or extra security, a Velcro strap is included.

You can even move the transmitter plate to the end of the handle, if preferred.

For XLR connections, you can use the DAD6001-BC Adapter for MicroDot to 3-pin XLR with Belt Clip (not included).

  • Directional pattern: Supercardioid
  • Principle of operation: Pressure gradient
  • Cartridge type: Pre-polarized condenser
  • Frequency response: 20 Hz - 20 kHz
  • Effective frequency range ±2 dB, at 20 cm (7.9 in): 80 Hz - 15 kHz with 2 dB soft boost at 10-12 kHz
  • Sensitivity, nominal, ±3 dB at 1 kHz: 16 mV/Pa; -36 dB re. 1 V/Pa
  • Equivalent noise level, A-weighted: Typ. 23 dB(A) re. 20 µPa (max. 26 dB(A))
  • Equivalent noise level, ITU-R BS.468-4: Typ. 35 dB (max. 38 dB)
  • Distortion, THD < 1%: 130 dB SPL RMS, 133 dB SPL peak
  • Dynamic range: Typ. 110 dB
  • Max. SPL, THD 10%: 135 dB SPL peak
  • Rated output impedance: From MicroDot: 30 - 40 Ω. From DAD4099-BC XLR Adapter: 100 Ω
  • Cable drive capability: Up to 300 m (984 ft) with DAD4099-BC XLR Adapter
  • Common mode rejection ratio (CMRR): > 60 dB from 50 Hz to 15 kHz with DAD4099-BC XLR Adapter
  • Power supply (for full performance): For wireless systems: Min. 5 V - max. 10 V through DPA adapter
  • With DAD6001-BC: P48 (Phantom Power). Will work from 12 V
  • Current consumption: Typ. 1.5 mA (microphone). 3.5 mA with DAD6001-BC XLR Adapter
  • Connector: MicroDot
  • Color: Black
  • Weight: 10 g (0.35 oz)
  • Microphone length: 10.4 cm (4 in)
  • Temperature range: -40°C to 45°C (-40°F to 113°F)
  • Relative humidity (RH): Up to 90%
  • 4097 Frequency response: Typical on and off-axis response of a 4097 microphone measured at 20 cm (7.9 in).
  • 1x 4097 CORE Micro Shotgun Microphone (4097-DC-G-B00-010)
  • 1x MicroDot Cable 2.2 mm (.09 in), 1.8 m (5.9 ft) (CM2218B00)
  • 1x Plate for transmitter
  • 1x Velcro strap 330 mm (13 in)
  • 1x Cold Shoe Mount with standard 1/4 in thread (CS4099)
  • 1x Rycote Windjammer (Rycote 055427, DPA 4099 Mini Windjammer)
  • 1x Telescope Boom (Manfrotto MPCOMPACT-BK)
