MRK16_STD - 16 channel ultra-wideband receiver

The MRK16 is a modular wireless microphone receiver system accommodating up to 16 channels in a compact 19” 1RU aluminum chassis. It supports up to 4 MCR54 receivers and offers antenna distribution, RF filtering, and advanced audio routing (analog, AES3, and Dante).

FEATURES

• Up to 16 True-Diversity Channels: Fits 4 MCR54 receivers in a compact 19” 1U rack.
• Ultra-Wideband Receiver System: Covers 470 to 1260 MHz with 10 automatically selected bandpass filters.
• RF Over Fiber: Enables reception without distance limitations! The optional EXP3 fiber module replaces coaxial cables, allowing antenna placement several kilometers away.
• Versatile Audio Outputs:
  - Digital: AES72 & AES59
  - Dante: Primary & Secondary
  - Analog: 2x DB25 (Tascam wiring)
• Dual Area Matrix: Allows selection and combination of two diversity zones. Supports antenna boosters and remote control of Wisycom LFA/ADFA/BFA.
• Bluetooth 5 Long Range: Class 1 (100 mW) connectivity for remote control of Wisycom devices over hundreds of meters.
• Daisy-Chain Functionality: Link up to 4 racks, enabling 64 channels in just 4U.
• Gigabit Ethernet Switch: Includes 5 ports, with ETH5 connected to an internal SFP module for fiber data transmission.
• Redundant Power Supply: Dual XLR inputs for fail-safe operation.
• Dual Power Over Ethernet (PoE) Input and Optional PoE Output (PE1): Provides additional power flexibility.
• USB-C Connectivity: Supports data and provides 1.5A power output.
