MTK982-EU - IEM/IFB transmitter

The Wisycom MTK982 is a versatile dual wideband stereo IEM/IFB transmitter. The MTK982 delivers the highest audio quality, extremely low spurious emissions, and the capability to generate various RF modulations.

Optional: DC power supply (10–28 VDC)

FEATURES

• 330 MHz Bandwidth
• Direct Digital Synthesis (DDS) of the signal for maximum flexibility and quality (> 70 dB stereo separation)
• Audio Modulations: Stereo, mono, intercom
• DSP audio processing (40-bit floating point / 2 GFlops) with multi-companding
• Output stage with low interference and wideband intermodulation phase cancellation
• 2400 User-Defined Frequencies: 40 groups with 60 channels each
• Analog & digital inputs (AES3)
• Output power up to 2 watts
• Redundant power supply: 230/110 VAC & 12 VDC (DC optional)
• SWR Detection: Standing wave ratio sensing on antenna outputs
• RF auxiliary outputs for isofrequency transmission (included as standard)
